Teledyne offers the complete range of Time Delay Integration (TDI) image sensor solutions from Earth observation land scanning using traditional CCD technologies through to next generation remote sensing CMOS TDI platform product families and hyperspectral and multispectral solutions.
Teledyne offers standard and customized packaging options and designs optimized for radiation hardness and extreme environments enabling cost-effective small satellite optical payload design.
Teledyne Imaging, building on its unmatched heritage in CCD TDI designs, offers charge-domain CMOS TDI, combining the noiseless summation advantages of CCD structures with the massively parallel on-chip analog-to-digital conversion of CMOS. The result: devices with the sensitivity and dynamic range of CCD with the speed and throughput of CMOS...built with our decades of experience designing and delivering solutions for the harshest environments.
The technology will support many emerging remote sensing applications such as land use mapping, urban infrastructure, agriculture, national resource management, disaster management, maritime, security and surveillance.
Resolution: 8192 × 80 Pixel size: 7 µm TDI CCD image sensor with 7 μm x 7 μm pixels, selectable outputs and 100x antiblooming.
Resolution: 12288 × 128 Pixel size: 7 µm Five band multispectral TDI CCD image sensor with selectable stages.
Resolution: 4096 × 96 Pixel size: 7 µm Backside illuminated five bands TDI CCD image sensor
Resolution: 12288 × 64 Pixel size: 7 µm dual zone, unidirectional TDI CCD with continuous vertical clocking and 16 or 8 selectable outputs per zone
Resolution: 24100 × 128 Pixel size: 7 µm Multispectral, multi-die TDI image sensor array
Resolution: 36200 × 128 Pixel size: 7 µm Backside thinned, multispectral, multi-die TDI image sensor array
Resolution: 12288 × 128 Pixel size: 7 µm 12k pixel backside illuminated, bidirectional, multispectral TDI CCD
Resolution: 16000 × 4 Pixel size: 5 µm Very high resolution CMOS time delay integration (TDI) image sensors with CCD on CMOS architecture designed for space satellite Earth observation (EO) applications.
