Teledyne e2v looks both ways with its sensors in JANUS on the JUICE mission

Chelmsford, UK, April 11, 2023 – Teledyne e2v, part of the Teledyne Imaging Group, delivered the CIS115 CMOS sensor (3Mp, 7µm pixel pitch) on JUICE’s optical camera JANUS. It will have a resolution up to 2.4 m on Ganymede and about 10 km at Jupiter. Teledyne e2v worked with the Open University to provide these CMOS devices to DLR in Germany. JUICE is ESA’s Jupiter Icy Moons Explorer, which will make detailed observations of the giant gas planet and its three large ocean-bearing moons – Ganymede, Callisto and Europa – with a suite of remote sensing, geophysical and in situ instruments. The mission will characterise these moons as both planetary objects and possible habitats, explore Jupiter’s complex environment in depth, and study the wider Jupiter system as an archetype for gas giants across the Universe.

JUICE is due to be launched on April 13 at UTC 12.15 (13.15 BST), from Europe's Spaceport in French Guiana and expected to reach Jupiter in 2031. In the interim 8 years, JUICE will be subject to the risks of radiation damage to its instruments and the threat of being pulled off-course by Jupiter’s gravitational force while having to survive extremely low-temperatures.

JANUS is just one of ten highly specialised instruments flying on JUICE that have been designed, tested and built to survive those risks. The sensor that Teledyne e2v supplied to JANUS, is a radiation hard CMOS imager which was tested in collaboration with the Open University. To ensure survivability, the sensor was put through a battery of tests which included electro-optical testing for very harsh radiation environment, mechanical shock and vibration, thermal cycling, extreme humidity, and an accelerated life test.

The CMOS image sensor for JANUS was designed for high reliability in a space environment whilst achieving high-quality performance and high sensitivity with unique back illumination technology. This has established a low-power platform for continued development of enhanced CMOS image sensors.

Daniel Waller, Vice-President and General Manager for Spacing Imaging at Teledyne e2v, said: “The launch of JUICE with the JANUS optical camera onboard marks a milestone in this important mission. This is our second CMOS sensor from our facility in Chelmsford to fly in space in recent months. This sensor will give us sight of both the icy moons and the environment of Jupiter, increasing our understanding of other planets in our solar system.  Since our team delivered the sensor for JANUS, R&D has continued at pace as we work towards other space missions.”

Ends

Notes to Editors

Funded ESA



Teledyne e2v is part of the Teledyne Imaging Group. Their leading-edge devices enable customer innovations through access to state-of-the-art technologies, driving the next generation of systems, in signal chain semiconductor devices, full spectrum imaging and high-power radio frequency solutions. Teledyne e2v engineers have led on ground-breaking improvements in cancer radiotherapy systems, ultra-high reliability in critical electronic systems, observing the effects of climate change from space and imaging planetary exploration in our solar system.

For more information, visit https://www.teledyne-e2v.com

Teledyne Imaging is a group of leading-edge companies aligned under the Teledyne Technologies [TDY] umbrella. Teledyne Imaging forms an unrivalled collective of expertise across the spectrum with decades of experience. Individually, each company offers best-in-class solutions. Together, they combine and leverage each other’s strengths to provide the deepest, widest imaging and related technology portfolio in the world. From aerospace through industrial inspection, scientific research, spectroscopy, radiography and radiotherapy, geospatial surveying, and advanced MEMS and semiconductor solutions, Teledyne Imaging offers world-wide customer support and the technical expertise to handle the toughest tasks. Their tools, technologies, and vision solutions are built to deliver to their customers a unique and competitive advantage.

For more information, visit https://www.teledyneimaging.com/

Contact:

Karyn Barnes

Head of Marketing - Space Imaging

Published 2023-04-12
Relevance: Aerospace & Defense Teledyne DALSA Teledyne e2v Teledyne Judson Teledyne Scientific and Imaging

JUICE’s camera (JANUS) will image Jupiter’s clouds and geological features on the moons in high resolution.
