Earth Observation Imaging & Living Planet Sciences
Earth Observation
Teledyne has a long history in enabling Earth Observation (EO) missions for ESA, NASA, JAXA and other space agencies to acquire observations of the Earth’s surface and atmosphere via remote sensing instruments. With aerospace technologies continually, evolving, remote sensing and digital data collection applications are increasing in Low Earth Orbit (LEO) and increasingly to airborne platforms. With an eye to the rapidly evolving market in High Altitude Pseudo Satellites (HAPS) Teledyne Imaging is developing its next generation product platforms with this in-mind.
Teledyne imaging’s sensor portfolio for Earth observation and remote sensing passive imagery covers the complete range of imaging techniques in the visible spectrum including panchromatic, multi-spectral, pan-sharpened and hyper-spectral. Specialist X-ray, ultraviolet (UV) and infrared solutions are also available.
With a complete portfolio in CCD devices and an ever-expanding range of front and backside illuminated radiation hardened CMOS detectors, you can be sure we can supply you with the solution for your mission that meets the spectral, data, functionality, cost and power requirements of the remote sensing instrument.
Key advantages from Teledyne Imaging
- Full spectrum and multi band (Visible to NIR through Infrared)
- High to very high pixel Focal Plane Arrays (FPAs) such as 4k to 12k pixel detectors to 24k and 36k silicon carbide dual and tri-detector focal planes
- Added CMOS on-chip functionality
- Low noise
- Low latch-up and resistant to Single Event Latch-up (SEL)
- Radiation tolerant
- Space / flight proven designs
- Custom spectral filters
Living Planet Sciences
Teledyne has a long history in enabling Earth Observation (EO) missions for ESA, NASA, JAXA and other space agencies, with the criticality of understanding the Earth system and its processes in the context of global change Teledyne has worked with ESA’s and NASA’s living planet programmes since the 1980’s which has directed technological image sensor development to meet these goals specifically.
Teledyne imaging’s sensor portfolio for living planet passive imagery covers the complete range of imaging techniques in the visible spectrum including panchromatic, multi-spectral, pan-sharpened and hyper-spectral. Specialist X-ray, ultraviolet (UV) and infrared solutions are also available.
With a complete portfolio in CCD devices and an ever-expanding range of front and backside illuminated radiation hardened CMOS detectors, you can be sure we can supply you with the solution for your mission that meets the spectral, data, functionality, cost and power requirements of the remote sensing instrument.
Our heritage
With more than 80 flown missions and programmes that the Teledyne Imaging group have provided the remote sensing detector for and more than 20 planned missions, Teledyne has a proven and enviable market leading position in space qualified imaging solutions.
Examples:
- ESA’s Copernicus Sentinel satellites – Visible, CMOS, CCD, TDI (Multi-spectral)
- Meteosat Third Generation
Key advantages from Teledyne Imaging
- Full spectrum and multi band (Visible to NIR through Infrared)
- Added CMOS on-chip functionality
- Low noise
- Low latch-up and resistant to Single Event Latch-up (SEL)
- Radiation tolerant
- Space / flight proven designs
- Custom spectral filters
Earth Observation Imaging and Living Planet Sciences Products
CCD275-42
Resolution: 1022 × 2050 Pixel size: 26 µm High readout rates and high signal capacity
CCD47-20
Resolution: 1024 × 1024 Pixel size: 13 µm Back illumination technology and extremely low noise amplifiers
CCD55-20
Resolution: 720 × 1152 Pixel size: 22.5 µm Full-frame imaging device with two image area sections that can be clocked separately
CCD55-30
Resolution: 1252 × 1152 Pixel size: 22.5 µm Full-frame imaging device with two image area sections that can be clocked separately
CCD69
Resolution: 16 × 16 Pixel size: 16 µm
CCD201-20
Resolution: 1024 × 1024 Pixel size: 13 µm Extreme performance in high frame rate ultra-low light applications
CCD351
Resolution: 1024 × 1024 Pixel size: 10 µm Extreme performance in high frame rate ultra-low light applications
CCD209
Resolution: 78 × 0 Pixel size: 13 µm
CCD325
Resolution: 450 × 1060 Pixel size: 28 × 42 µm
IC-43-24100
Resolution: 24100 × 128 Pixel size: 7 µm Multispectral, multi-die TDI image sensor array
IC-48-36200
Resolution: 36200 × 128 Pixel size: 7 µm Backside thinned, multispectral, multi-die TDI image sensor array
IA-DM-01024
Resolution: 1024 × 1024 Pixel size: 8.5 µm Frame transfer CCD array image sensor with 8.5 μm pixel, MPP mode and 100x antiblooming
IC-22-08192
Resolution: 8192 × 80 Pixel size: 7 µm TDI CCD image sensor with 7 μm x 7 μm pixels, selectable outputs and 100x antiblooming.
IC-50-12288
Resolution: 12288 × 128 Pixel size: 7 µm 12k pixel backside illuminated, bidirectional, multispectral TDI CCD
IC-34-12288
Resolution: 12288 × 64 Pixel size: 7 µm dual zone, unidirectional TDI CCD with continuous vertical clocking and 16 or 8 selectable outputs per zone
IC-35-02208
Resolution: 2208 × 320 Pixel size: 30 µm Split frame transfer backside thinned area array CCD image sensor with 30 μm x 30 μm pixels, selectable outputs and exposure control
Capella
Resolution: 2048 × 2048 Pixel size: 10 µm Highly flexible CMOS image sensor platform designed for a large range of space applications.
Orbis
Resolution: 16000 × 4 Pixel size: 5 µm Very high resolution CMOS time delay integration (TDI) image sensors with CCD on CMOS architecture designed for space satellite Earth observation (EO) applications.
Sapphire
Resolution: 1280 × 1024 Pixel size: 5.3 µm 1.3 Mpixels B&W and Color CMOS Image Sensor
Ruby
Resolution: 1280 × 1024 Pixel size: 5.3 µm 1.3 Mpixels B&W and Color CMOS Image Sensor
Custom CMOS Sensors
Resolution: 244 × 488 Pixel size: 70 µm space qualified CMOS image sensors, with unparalleled performance in terms of sensitivity, radiation tolerance and low power consumption.
